R1: 600
600 ohms. R2: 500,000
ohms.
R3: 3000 ohms. C1, C3:
.0005.
Tr.: .00005 m.f.d. trimmer
trimmer.
C4, C5: 1 m.f.d., 500 test.
C2, C6:
.5 m.f.d., 500 test.
