Diagram Correction

Inductance Coil Design ey "Radio Record" dated August 238 , there appeared on page 80 a diagram, but the explanatory matter relating to curves "A," "B," "CO" was transposed. It appears below in corrected form. Readers are advised to cut out the corrected lines: and paste them over those appearing previously. Top.-A 200 mh, coil tuned with .0005 mfd. condenser.. Centre-A 280 mh. coil tuned with .00035 mfd. condenser. Lower.-A 340 mh. coil tuned with ‘,00025 mfd. condenser. "A" denoting a 3-inch former; "RB", 2.53 "CO", 2.
