not quits so decisive as it was BUT A DITTOS MORE OVK3WHKLMINO. W& CHALLENGE the representative of the Singer Sewing Machine Company, or any of the jar ora bn Sewing Machines at the Exhibition who vpJtbd’Tor the report coming from that body, to'qonlroverk the following statement of ’ foots. Messrs Weddings, Cnnnington, Dale; and Kirk, we oilt opon yon r to defend'your report. ’ ■ 1'- * CO. Christohuroh International Exhibition, Jane 15th, 1882 REPORT OP COMMITTEE OF EXPERTS. To H. C. Piske & Co. T\EAS SIB, —In accordance with yonr JLP request, we have examined the New Davia and the New Singer Sewing Machines, for the pnrpoae of comparing them. In oar comparison we have take a Into consideration—

1. 'J he mechanical principle Involved 2. The quality of the material tned 3 The degree of workmanship exhibited 4. The facility for doing a good and varied o ass of work. After taking both maohlnes asunder, care-

fully examining every piece, and fully testing their capabilities, we have no hesitation in saying that we consider the Davis far the superior machine of the two. Oar reasons are as follows : In both machines the same method is adopted for actuating the needle bar, viz., a crank with roller working in a cam. This osm in the Davis Machine is cot oat of a t solid piece of steel and hardened, while in the Singer it is not only very much lighter, ■ but is made of common oast iron. The feed apparatus of the two machines' are very dissimilar. That of the Singer is the usual slip feed. The Davis has the vertical feed peculiar to itself. In this arrangement the preaser foot holds the material firmly down till the needle has reached its lowest point. The pressure is theu relieved and transmitted to the feed bar. Feed bar, needle, and material are then, by a very simple contrivance, moved forward simultaneously the required length of stitoh.

Motion la giv* n to the shuttle in the Davis machine as follows An eccentric at the wheel end of the main spindle gives motion to a vertical lever. This in tarn transmits it through a ball joint of ingenious construe tlon to the only moving part under the machine, a pivotted lever having at its end an adjustable shuttle carrier. In the Singer Machine a pair of mitre wheels drive a vertical spindle, having at its lower end a crank. A connecting rod from this crank moves a sliding shuttle carrier. It will be seen that in the Davis there are between the main spindle and the shuttle four points of friction, the pivot carrying the vertical lever, the eccentric, the ball joint, and the pivot of horizontal lever. The two principal movements, the eccentric and the ball joint, are adjustable, and the parts most liable to wear are made of hardened steel. To compass the same work the Singer employs as points of friction the teeth of the mitre wheels, the two journals of vertical spindle, the two ends of the connecting rod, and the sliding shuttle carrier None of these places are adjustable. The small wheels are common cast iron, having a certain amount of backlash, and consequent tendency to rattle and and break. The connecting rod is a thin bar cf iron, with a hole in each end. The end which runs on the crank pin is one of the principal joints in the machine, having a considerable amount of work to do with small bearing surface, making it very liable to wear, while, as before remarked, there are no means qf compensating for any wear. It will be noticed that the shuttle of the Singer Machine is carried in a slide, to which a lateral strain is given by the driving rod, causing a certain amount of friction, while in the Davis It is carried by the lever quite free from Motion. With the exception of the small roller working the needle bar, there is not a single piece in the Singer Machine, not even excepting the shuttle, that oat not be out with an ordinary pocket knife, and there are no means of adjusting any wearing part. In the Davis not only are most of the pieces made of steel, and tempered, but at every essentia] point means are provided for taking up any wear. On this point we may say I that where we had any doubt about the quality of the material employed the the piece was broken and the fracture carefully examined. Having examined the mechanical arrangements of the two machines, we tested their adaptability for work, end we noticed the very peonliar feed of the Davis. In this respect wo have been forced to the conclusion that for all purposes, sewin from the thinnest muslin to even throu h a metal spoon, the Davis has no paralle grasp, or for avoiding that puckering often the effect of the pressure on a fore motion feed. We must In common honesty express our astonishment at the range and variety of work accomplished by the Davis, which we are satisfied cannot be done by the Singer. In summarising our report we repeat that we have no hesitation in saying that we regard the Davis as very superior to the Singer in workmanship,' material, and the mechanical principles involved, and also in performing a greater range cf work. We found the Davis to work with equal ease from the lightest to the heaviest fabric. JOHN LEE SOOTT (Scott Bros.), Mechanical Engineer. T. GLUYAB PABCOB, M anager of the Kaiapoi Clothing Factory. GEJO, P. ANTHONY, Mechanical Expert, from Nettlefold’s, Birmingham. 8300
